Mini Double-Deck Robot Car Kit

Mini Double-Deck Robot Car Kit

This kit is an excellent introduction to robotics and STEM education. It encourages creativity, logical thinking, and hands-on experimentation.

Specifications

• Outline Size: 135 x 135 x 80 mm
• Round Acrylic Plate Diameter: 130 mm
• Acrylic Baseboard Size: 135 x 75 mm

Features

• Compact and Cool Design: The round double-deck chassis is sleek and highly functional.
• Easy Assembly: Comes with all required parts for quick and simple assembly.
• Customizable Platform: Add microcontrollers, sensors, and modules to build your own robot.
• Educational and Fun: Introduces robotics and programming concepts engagingly.
• Durable Materials: High-quality acrylic plates and sturdy components ensure durability.

Package Includes

• 1 x Round Acrylic Plate: Top layer for mounting sensors and controllers.
• 1 x Acrylic Baseboard: Bottom layer for motor and battery mounting.
• 2 x 65mm Wheels: Provide stable and smooth movement.
• 2 x Universal Wheels: Support multi-directional mobility.
• 2 x Gear Motors: Power the wheels for movement.
• 4 x “T” Mode Fixed Motor Brackets: Securely hold motors in place.
• 16 x M3 x 10mm Screws: For assembling the chassis.
• 8 x M3 Nuts: Secure connections during assembly.
• 4 x M3 x 12+6mm Copper Cylinders: For structural support.
• 4 x M3 x 30mm Two-Way Copper Columns: For connecting and spacing the two decks.

Assembly Instructions

Step 1: Prepare Your Kit

• Unpack the components and arrange them.
• Verify that all parts match the “Package Includes” list.

Step 2: Assemble the Motors and Brackets

• Attach the gear motors to the “T” mode fixed motor brackets using screws and nuts.
• Secure the assembled motor brackets to the acrylic baseboard.

Step 3: Attach the Wheels

• Fix the 65mm wheels to the motor shafts.
• Mount the universal wheels to the underside of the baseboard for added stability.

Step 4: Construct the Chassis

• Use the M3 x 12+6mm copper cylinders and M3 x 30mm two-way copper columns to connect the round acrylic plate to the baseboard, creating the double-deck structure.

Step 5: Add Electronics (Optional)

• Mount your microcontroller, sensors, and other modules on the round acrylic plate.
• Connect the motors and sensors to the microcontroller using appropriate wiring.

Step 6: Test Your Robot

• Power the system using a battery pack (not included).
• Program your microcontroller to control the robot’s movement and functionality.

Educational Benefits

• Hands-On Learning: Build and customize your robot, fostering creativity and problem-solving skills.
• STEM Education: Learn concepts in robotics, electronics, and programming.
• Logical Thinking: Understand mechanical assembly and how different components work together.

Applications

• Build line-following or obstacle-avoiding robots.
• Experiment with programming and sensor integration.
• Use as a base platform for school projects or hobby robotics.

Why Choose This Kit?

The 2WD Mini Round Double-Deck Robot Car Kit offers a simple yet powerful introduction to robotics. Its compact design, ease of assembly, and expandability make it ideal for beginners and young engineers. Whether you’re exploring robotics for fun or working on a project, this kit provides the tools to bring your ideas to life.
